Audiolab 9000A Integrated Amplifier
NEW
Audiolab 9000 A, Stereo Integrated Amplifier with integrated DAC and Phono-Stage (MM).
[Finish: Black or Silver]
Description
Audiolab 9000A – Versatile Premium Integrated Amplifier
The Audiolab 9000A is the heart of any audiophile hi-fi system, impressing with its exceptional sound quality and flexibility. With 100 watts per channel into 8 ohms, the amplifier offers ample power to effortlessly drive even demanding loudspeakers. The 9000A excels at playing back both analog and digital sources and integrates seamlessly into a wide variety of audio setups. Thanks to its three operating modes – Integrated, Pre-Power, and Pre-Only – it is versatile enough to be used as an integrated amplifier , preamplifier , or power amplifier , making it one of the most flexible devices on the market.
Phono and Headphone Amplification
Audiolab has equipped the 9000A with a high-quality phono preamplifier specifically optimized for moving magnet (MM) cartridges. Thanks to its JFET circuitry and precise RIAA equalization, the amplifier delivers a clean, detailed, and authentic reproduction of vinyl records. Audiophile vinyl enthusiasts will love the clarity and detail of the record playback. In addition, the 9000A features a powerful headphone amplifier with current-feedback technology , providing dynamic and detailed sound for all popular headphone models
Display and Ease of Use
The 9000A's large 4.3-inch IPS TFT color display not only makes operation easy but also provides an appealing visual presentation of all important information. The menu navigation is intuitive and allows the user to make all settings quickly and easily. This makes the amplifier a true pleasure to use every day
High-quality DAC and digital signal processing
At the heart of the Audiolab 9000A lies the ESS Sabre ES9038PRO DAC , one of the best digital-to-analog converters on the market. This high-resolution DAC supports 32-bit/768 kHz and DSD512 , ensuring extremely precise and detailed playback. This makes the 9000A the perfect choice for lovers of high-resolution audio formats. Whether from streaming services, CDs, or local sources, the 9000A brings out every detail of the music, delivering an unparalleled listening experience.
9000A Specifications
| Model | 9000A |
| General Description | Integrated Amplifier |
| Design Philosophy and Core Technology | 2 x 100W (8 ohms) / 2 x 160W (4 ohms) Class AB ES9038Pro 32-bit DAC 4.3" (800 x 480px) Large Size Full View IPS LCD Built-in Certified MQA Full Decoder (PC USB, Coax/Optical) Bluetooth 5.1 (aptX/aptX HD/AAC/LDAC) Support Dedicated High-performance, Low-noise MM Phono Stage Dedicated Current-Feedback Headphone AMP Integrated / PRE-POWER / PRE Only Modes USB Upgrade Support |
| Inputs | 3 x Analogue, 1 x XLR, 1 x Phono (MM), 1 x Power Amplifier, 2 x SPDIF (Coax), 2 x SPDIF (Optical), 1 x PC USB (USB B - Windows / mac OS only), 1 x Bluetooth (aptX/aptX HD/LDAC), 1 x 12V Trigger |
| Outputs | 1 x PRE Amplifier,1 x Stereo Speaker, 1 x Headphone, 1 x 12V Trigger |
| Sampling Frequency | Optical / Coaxial: 44.1kHz-192kHz; PC USB: 44.1kHz-768kHz (PCM) / DSD64, DSD128, DSD256, DSD512 |
| Preamplifier Section | |
| Gain (max.) | +6dB (Line), +53dB (Phono MM) |
| Input Sensitivity | 1Vrms (Line, Volume = 0dB); 2Vrms (XLR, Volume = 0dB), 4.4mV (Phono MM, Volume=0dB) |
| Input Impedance | 10K (Line); 47K // 100pF (Phono MM) |
| Total Harmonic Distortion (THD) | < 0.0004% (1kHz @ 2V, Volume = 0dB) |
| Frequency Response | 20Hz-20kHz (+/-0.1dB) |
| Output Voltage | 2.3V max. (Volume = 0dB) |
| Output Impedance | 120 ohms |
| Signal-to-Noise Ratio | > 110dB (Line & XLR, A-weighted); > 80dB (Phono MM, A-weighted) |
| DAC | |
| D to A Converter | ES9038Pro |
| Total Harmonic Distortion (THD) | < 0.001% (1kHz @ 0dBFS) |
| Output Level (0dBFS, 1kHz) | 2.1Vrms |
| Max. Sampling Frequency | Optical, Coaxial: 192kHz; PC USB: PCM768kHz, DSD512 |
| Signal-to-Noise Ratio (S/N) | > 117dB (A-weighted) |
| Power Amplifier Section | |
| Gain | +29dB |
| Rated Power Output | 2 x 100W (8 ohms, THD<1%); 2 x 160W (4 ohms, THD<1%) |
| Frequency Response | 20Hz-20kHz (+/-0.3dB) |
| Total Harmonic Distortion (THD) | <0.002% (1kHz @ 50W / 8 ohms) |
| Input Sensitivity | 1Vrms |
| Signal-to-Noise Ratio (S/N) | > 110dB (A-weighted) |
| Max. Output Current | 15A |
| Headphone Amplifier | |
| Total Harmonic Distortion (THD) | < 0.01% (1kHz, 50mW ) |
| Output Impedance | 2.35 ohms |
| Load Impedance | 20-600 ohms |
| General | |
| Standby Power Consumption | <0.5W |
| Net Weight | 9.4kg |
| Gross Weight | 11.2kg |
| Dimensions (mm) (W x H x D) | 444 x 89 x 342 |
| Carton Size (mm) (W x H x D) | 514 x 470 x 161 |
| Finish | Black / Silver |
| Power Requirements | 220-240V ~ 50/60Hz; |
| (depending on region) | 100-120V ~ 50/60Hz |
| Standard Accessories | Power Cord, Remote Control, User Manual, Antennas, etc. |
